POWER TEAM HYDRAULIC CYLINDERS
.jpg)
All Power Team cylinders are date coded and stamped with a maximum pressure rating and capacity. Each cylinder we make complies with the demanding ASME B30.1 standard and are assembled/tested by certified assemblers and pressure tested to 125% of capacity before leaving our factories. Some other key features included:
Some other key features included:
• Cylinder bores are roller burnished to harden and smooththe surface, improving seal life by 30%.
• Base mounting holes withstand full cylinder capacity.
• Typical cylinder burst pressure range is from 25,000 to35,000 psi, well-beyond extreme usage.
• Cylinders with gland nuts may be “dead-ended” at 10,000psi.
• Eddy current and mag-particle inspections detect flaws inthe steel.
• Material is removed from surface to ensure that any flawsare eliminated.
Some other key features included:
• Cylinder bores are roller burnished to harden and smooththe surface, improving seal life by 30%.
• Base mounting holes withstand full cylinder capacity.
• Typical cylinder burst pressure range is from 25,000 to35,000 psi, well-beyond extreme usage.
• Cylinders with gland nuts may be “dead-ended” at 10,000psi.
• Eddy current and mag-particle inspections detect flaws inthe steel.
• Material is removed from surface to ensure that any flawsare eliminated.
